Đặc tính kỹ thuật

Model FG-100E-BDL-950-12
Interface 2x GE RJ45 MGMT/DMZ Ports
2x GE RJ45 WAN Ports
2x GE RJ45 HA Ports
14x GE RJ45 Ports
2x GE RJ45/SFP Shared Media Pairs
Bundle Hardware plus 24×7 FortiCare and FortiGuard Unified (UTM)
Interfaces and Modules
GE RJ45 Ports 14
GE RJ45 Management/HA/DMZ Ports 1/2/1
GE RJ45 WAN Ports 2
GE RJ45 or SFP Shared Ports 2
USB Port 1
Console Port 1
Included Transceivers 0
System Performance — Enterprise Traffic Mix
IPS Throughput 2,500 Mbps
NGFW Throughput 2,4360 Mbps
Threat Protection Throughput 2,5250 Mbps
System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte, UDP) 7.4 / 7.4 / 4.4 Gbps
Firewall Latency (64 byte, UDP) 3 μs
Firewall Throughput (Packet per Second) 6.6 Mpps
Concurrent Sessions (TCP) 2 Million
New Sessions/Second (TCP) 30
Firewall Policies 10
IPsec VPN Throughput (512 byte) 4 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 2
Client-to-Gateway IPsec VPN Tunnels 10
SSL-VPN Throughput 250 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) 500
SSL Inspection Throughput (IPS, avg. HTTPS) 130 Mbps
SSL Inspection CPS (IPS, avg. HTTPS) 130
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3125
Application Control Throughput (HTTP 64K) 1 Gbps
CAPWAP Throughput (1444 byte, UDP) 1.5 Gbps
Virtual Domains (Default / Maximum) 10/10
Maximum Number of FortiSwitches Supported 24
Maximum Number of FortiAPs (Total / Tunnel) 64 / 32
Maximum Number of FortiTokens 5
Maximum Number of Registered FortiClients 600
High Availability Configurations Active / Active, Active / Passive, Clustering
Dimensions and Environment
Height x Width x Length 1.75 x 17.0 x 10.0 inches
44.45 x 432 x 254 mm
Form Factor Rack Mount, 1 RU
Power Required 100–240V AC, 60–50 Hz
Maximum Current 100V / 0.52A, 240V / 0.22A
Power Consumption (Average / Maximum) 23.0 W / 28.6 W; 51.9 VA
Heat Dissipation 97.6 BTU/h
Operating Temperature 32–104°F (0–40°C)
Storage Temperature -31–158°F (-35–70°C)
Humidity 10–90% non-condensing
Noise Level 40.4 dBA
Operating Altitude Up to 7,400 ft (2,250 m)
Compliance FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL,
CB, BSMI
Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN;IPv6

– Bảo hành: 12 tháng.
