Vigor2927Fac High Througput Enterprise Dual Wan Load Balancing VPN Fiber Router:
– Router quang VPN Wan kép chuyên nghiệp cho Doanh Nghiệp/ Nhà Hàng / Khách Sạn chịu tải 150 user- Hỗ trợ WiFi Marketing
– WAN 1 cổng quang gắn SFP 1.25Gbps, 1 hoặc 2 sợi quang
– WAN 2 có thể chuyển đổi WAN/LAN Gigabit Ethernet, RJ45.
– 5 cổng Lan Gigabit, hỗ trợ VLAN tag 802.1q chia 16 VLAN (8 Subnet)
– 2 cổng USB kết nối USB 3G/4G, Printer,…
– NAT Session: 60.000 / NAT Throughput: 1.8 Gbps (Dual Wan), chịu tải 150 user
– Cân bằng tải (cộng gộp băng thông) hoặc dự phòng các đường truyền internet (Loadbalance/ Failover
– Hỗ trợ triển khai dịch vụ cao cấp: Static IP, PPOE, PPTP/L2TP, DHCP…
– Hỗ trợ các dịch vụ: Leasedline, L2VPN, L3VPN, MetroNET… trên sub interface (NAT hoặc Routing)
– Hỗ trợ đường truyền đa dịch vụ (IPTV, Internet, VoIP,…)
– VPN Server 50 kênh (PPTP, L2TP, IPSec(IKEv1, IKEv2), SSL), Open VPN + SSL VPN: 25
– IPsec VPN Performnace: 290Mbps / SSL VPN Performance: 120Mbps
– Kiểm soát và quản lý băng thông giúp tối ưu hóa đường truyền internet
– Firewall mạnh mẽ, linh hoạt, quản trị phân quyền truy cập Internet (IP/MAC Address, Port Service, URL/Web content filter, schedule…), Firewall SPI dựa trên đối tượng, quản lý nội dung (CSM).
– Web portal: Hiện trang quảng cáo khi khách hàng kết nối internet
– Tích hợp Wi-Fi Marketing từ các nhà phát triển hàng đầu như Meganet, VNWIFI, Nextify…
– DrayDDNS tên miền động miễn phí của DrayTek
– Quản lý tập trung VPN cho 8 site Router Vigor khác qua Internet (CVM)
– Quản lý tập trung cho 20 Access Point (APM), 10 Switch (SWM)
– Quản lý tập trung Vigor2927 bằng phần mềm DrayTek VigorACS 2 hoặc cloud DrayTek Free
Thông số kỹ thuật:
PHẦN CỨNG |
Port |
- 1 x SFP 100/1000Mbps WAN
- 1 x GbE WAN
- 5 x GbE LAN
- 2 x USB 2.0
|
Nguồn |
|
Nút điều khiển |
|
PHẦN MỀM |
WAN |
- Ethernet WAN
- DHCP Client
- Static IP
- PPPoE
- PPTP / L2TP (WAN-2 only)
- 802.1q Multi-VLAN Tagging
- IPv6 Connection Type
- Dual Stack: PPP, DHCPv6 Client, Static IPv6
- Tunnel Mode: TSPC, AICCU, 6rd, 6in4 Static Tunnel
- USB WAN
- PPP(3G) / CDC driver(3G) / support IPv6 protocol :TSPC/AICCU
Dual WAN
- Load-Balance / Route Policy
- Outbound policy-based load-balance
- WAN Connection Failover
- Multiple-VLAN
|
Network |
- Hotspot Web Portal
- Packet Forwarding Acceleration
- DHCP client/relay/server
- DHCP Option: 1,3,6,51,53,54,58,59,60,61,66,125
- IGMP v2/v3
- LAN DNS /DNS Forwarding
- Dynamic DNS
- NTP Client
- RADIUS /TACACS+ Client
- Internal RADIUS Server
- Active Directory /LDAP compatible (client)
- DNS Cache/Proxy and LAN DNS
- UPnP 50 sessions
- Wake on LAN
- Bonjour service
- Routing Protocol:
- Static Routing
- RIP v1/v2
- BGP
- Triple-Play Application
- 8 x Multiple Subnet LAN
|
Management |
- Web-based User Interface (HTTP/HTTPS)
- CLI (Command Line Interface, Telnet/SSH)
- Administration Access Control
- Configuration Backup/Restore
- Built-in Diagnostic Function
- Firmware Upgrade via TFTP/HTTP/TR-069
- Logging via Syslog
- SNMP v2/v3
- Support SMS/E-mail Alert
- Management Session Time Out
- Two-level Management (Admin/User Mode)
- External device detection (master mode)
- TR-069/TR-104
- Support Multiple-Firmware Upgrade Utility (MFUU)
- Dashboard
|
Chất lượng dịch vụ |
- QoS
- Guarantee bandwidth for VoIP
- Class-based bandwidth guarantee by user-defined traffic categories
- DiffServ Code Point classifying
- 4-level priority for each direction (Inbound/Outbound)
- Bandwidth borrowed
- Bandwidth/Session limitation
- Smart Bandwidth Limit
- config by ip range
- Layer-3 (TOS/DSCP) QoS
- Layer-2 (802.1p) QoS
- WAN budget
|
VPN |
- Up to 50 VPN Tunnels (including 25 SSL VPN tunnels)
- VPN Wizard
- VPN Trunk with Backup / Load Balance
- Protocol : PPTP, IPsec, L2TP, L2TP over IPsec, GRE over IPSec
- Encryption : MPPE and hardware-based AES/DES/3DES
- Authentication : SHA
- IKE Authentication : Pre-shared Key and Digital Signature (X.509)
- LAN-to-LAN, Teleworker-to-LAN (remote user dial-in)
- DHCP over IPsec
- IPsec NAT-traversal (NAT-T)
- Dead Peer Detection (DPD)
- VPN Pass-through
- mOTP
|
Tính năng nâng cao |
Firewall
- DMZ Host:Port-redirection, Open Port, Port Triggering
- User-based / Rule-based Firewall
- Object-based Firewall:SPI (Stateful Packet Inspection) (Flow Track)
- DoS Prevention
- Time Schedule Control
- DNS Filter Enhancement
- User Management
- Firewall Wizard Mode and Advanced Mode
CSM (Content Security Management)
- APP Enforcement
- Support APPE Signature Upgrade by license
- URL Content Filter
- Access Control : URL Keyword Blocking (White/Black List)
- Web Feature : Java Applet, Cookies, Active X, Compressed, Executable, Multimedia File Blocking
- Web Content Filter (support Cyren and BPjM)
- DNS Filter
Central Device Management
- AP Management
- VPN Management
- Switch Management
- External Devices
|
USB |
- File System
- Support FAT32 File System
- Support FTP Function for File Sharing
- 3.5G (HSDPA) and 4G (LTE) as WAN3/WAN4 by using USB dongle (can support Dual USB WAN)
- USB Device Status (disk/modem/printer/sensor)
- Support USB Temperature Sensor
- Support file sharing (DrayTek’s own SMB protocol stack)
|
THÔNG SỐ KHÁC |
Môi trường |
- Temperature Operating : 0°C ~ 45°C
- Temperature Storage : -25°C ~ 70°C
- Humidity :10% ~ 90% ( non-condensing )
|
