Vigor2912F High Throughput Load Balancing Fiber Router:

– Router quang cân bằng tải chuyên nghiệp cho Doanh nghiệp – Hỗ trợ WiFi Marketing
– WAN 1: cổng quang gắn SFP quang 155Mbps hoặc 1.25Gbps, 1 hoặc 2 sợi quang (chưa bao gồm)
– WAN 2: 10/100Mbps, RJ45 (chuyển đổi từ LAN1)
* WAN 3: USB 2.0 gắn 4G/LTE USB modem
– 4 port LAN 10/100Mbps; Hỗ trợ chia 2 lớp mạng khác nhau (801.2q Vlan tag)
– NAT Session: 30.000; NAT Throughput: 93Mbps, chịu tải 50 user
– VPN Throughput: 90Mbps
– Cân bằng tải (cộng gộp băng thông) hoặc dự phòng các đường truyền internet (Loadbalance/ Failover)
– Hỗ trợ đường truyền đa dịch vụ (IPTV, Internet, VoIP,…)
– Triển khai các dịch vụ: Leasedline, L2VPN, L3VPN, MetroNET,…trên sub interface (NAT hoặc Routing)
– VPN Server 16 kênh (PPTP, L2TP, IPSec); VPN Trunking (Backup); VPN qua 3G/4G (Dial-out)
– Kiểm soát và quản lý băng thông giúp tối ưu hóa đường truyền internet
– Web Portal: Hiện trang quảng cáo khi khách hàng kết nối internet
– Firewall mạnh mẽ, linh hoạt, quản trị phân quyền truy cập Internet (IP/MAC Address, Port Service, URL/Web content filter, schedule,…)
– DrayDDNS tên miền động miễn phí của DrayTek
– Quản lý theo user name / password; Hỗ trợ chứng thực qua máy chủ Radius/LDAP
– Quản lý tập trung Vigor2912 bằng phần mềm DrayTek VigorACS 2 hoặc cloud DrayTek Free

Thông số kỹ thuật:

PHẦN CỨNG
Port
  • 1 x 10/100 Base-TX WAN, slot SFP, Configurable WAN2 on P1
  • 4 x 10/100 Base-TX LAN, RJ45
  • 1 x USB Host 2.0 (for 3G USB Modem/USB Disk)
Nguồn
  • DC 12V/1A
Nút điều khiển
  • 1 x Factory Reset Button
PHẦN MỀM
WAN
  • IPv4 Ethernet WAN
    • DHCP Client
    • Static IP
    • PPPoE
    • PPTP
    • L2TP
    • 802.1p/q Multi-VLAN Tagging
  • IPv6 Ethernet WAN
    • Tunnel Mode:
      • PPP
      • TSPC
      • AICCU
      • 6in4
      • 6rd*
    • Dual Stack:
      • DHCPv6 Client
      • Static IPv6
      • DSLite*
  • USB WAN
    • PPP
  • Outbound Policy-based Load-balance
  • WAN Connection Failover
  • 30,000 NAT Sessions
Network
  • DHCP Client/Relay/Server
  • RADVD for IPv6
  • DHCPv6 Server
  • Static IPv6 Address Configuration
  • IGMP Proxy V2/V3
  • IGMP Snooping
  • Dynamic DNS
  • NTP Client
  • RADIUS Client
  • DNS Cache/Proxy
  • UPnP 30 Sessions
  • Routing Protocol:
    • Static Routing
    • RIP V2
  • VLAN Tagging(802.1q) on LAN*
  • Support Route Policy Function
Management
  • Web-based User Interface (HTTP/HTTPS)
  • Quick Start Wizard
  • CLI (Command Line Interface, Telnet/SSH)
  • Administration Access Control
  • Configuration Backup/Restore
  • Built-in Diagnostic Function
  • Firmware Upgrade via TFTP/FTP/HTTP/TR-069
  • Logging via Syslog
  • SNMP V2/V3
  • Management Session Time Out
  • Two-level Management (Admin/User Mode)
  • External Device
  • TR-069
  • Support Smart Monitor (Up to 30 PCs)
Chất lượng dịch vụ

  • QoS :
    • Guarantee Bandwidth for V oIP (VoIP QoS)
    • Class-based Bandwidth Guarantee by User-defined Traffic Categories
    • DiffServ Code Point Classifying
    • 4-level Priority for Each Direction (Inbound/Outbound)
    • Bandwidth Borrowed
  • Bandwidth/Session Limitation
  • Layer-3 (TOS/DSCP) QoS Mapping
  • Smart Bandwidth Limitation (Triggered by Traffic/Session)


VPN
  • Up to 16 VPN Tunnels
  • Protocol : PPTP, IPSec, L2TP, L2TP over IPSec
  • Encryption : MPPE and Hardware-based AES/DES/3DES
  • Authentication : MD5, SHA-1
  • IKE Authentication : Pre-shared key and Digital Signature (X.509)
  • LAN-to-LAN, Host-to-LAN
  • IPsec NAT-traversal (NAT-T)
  • Dead Peer Detection (DPD)
  • VPN Backup Mode
  • DHCP over IPSec
  • VPN Pass-through
  • VPN Wizard
  • mOTP
Tính năng nâng cao

Firewall

  • Multi-NAT, DMZ Host, Port-redirection and Open Port
  • Object-based Firewall
  • MAC Address Filter
  • SPI (Stateful Packet Inspection) (Flow Track)
  • DoS/ DDoS Prevention
  • IP Address Anti-spoofing
  • E-mail Alert and Logging via Syslog
  • Bind IP to MAC Address
  • Time Schedule Control
  • User Management

CSM

  • (Content Security Management)
  • IM/P2P Application
  • GlobalView Web Content Filter (Powered by CYREN )
  • URL Content Filter :
  • URL Keyword Blocking (Whitelist and Blacklist)
    Java Applet, Cookies, Active X, Compressed, Executable, Multimedia File Blocking,
  • Excepting Subnets


USB
  • File Sharing:
    • Support FAT32 File System
    • Support FTP Function for File Sharing
    • Support Samba for File Sharing
  • 3.5G (HSDPA)/4G (LTE)* as WAN3
THÔNG SỐ KHÁC
Môi trường

  • Temperature Operating : 0°C ~ 45°C
  • Temperature Storage : -25°C ~ 70°C
  • Humidity 10% ~ 90% ( non-condensing )
