Port |
Fiber |
1*1000 Base-X |
RJ45 |
1*10/100/1000 Base-T |
Power |
Phoenix terminal blocks, redundant |
Distance |
Twisted-pair |
0-100meter |
Single mode Optical Fiber |
0~20km |
Multi-mode Optical Fiber |
2km |
Fiber |
Wavelength |
1310nm |
Connector |
SC(default)/FC/ST/LC |
Networking |
Star/Bus/Tree Topology |
Support |
Scale |
Non-limitation |
Power |
Input Voltage |
DC10-58V |
Power Consumption |
<5W |
Layer 2 |
Switching Capacity |
10G |
Packet Forwarding Rate |
7.44Mpps |
MAC Address Table |
8K |
Buffer |
1M |
Forwarding Delay |
<4us |
RJ45 Port |
Twisted-pair, adaptive |
Jumbo Frame |
10K bytes |
Traffic Control |
Support |
Mechanical Structure |
Installation Method |
Din-rail |
LED Indicator |
PWR,Link/ACT |
Case |
Fan-less, natural cooling |
Dimension |
118*91*31mm |
Weight |
0.36kg |
Working Environment |
Operating Temperature |
-400C~+750C |
Storage Temperature |
-450C ~+850C |
Relative Humidity |
5%~95% (non-condensing) |
MTBF |
100,000 Hours |
Protection Level |
IP Level |
IP40 |
Power -Surge Protection |
IEC 61000-4-5 Level 3 (4KV/2KV)(8/20us) |
Ethernet Surge Protection |
IEC 61000-4-5 Level 3 (4KV/2KV)(10/700us) |
EMI |
CLASS A |
ESD |
IEC 61000–4-2 Level 4 (8K/15K) |
Free-drop |
0.5meter |
Anti-static |
8KV-15KV |
